Tsubaki Chain Co., Ltd. CR5108 Roller Chain Kit

Description:

The Tsubaki CR5108 Roller Chain Kit is used in industrial power transmission systems to connect rotating shafts while accommodating shaft misalignment and transmitting torque through a flexible roller chain coupling. Commonly installed in conveyor systems, pumps, compressors, mixers, packaging machinery, and material handling equipment requiring flexible shaft coupling assemblies. Maintenance teams and system integrators use this coupling kit for repair, retrofit, expansion, or replacement to restore reliable torque transmission and simplify equipment maintenance.

Applications:

The Tsubaki CR5108 roller chain kit includes two CR5018-J coupling sprockets with a 32 mm finished bore and a CR5018 duplex roller chain to create a complete flexible coupling assembly. The wrap-around chain design allows installation or removal without repositioning connected equipment, while accommodating angular, parallel, and axial shaft misalignment. It is widely used in conveyors, pumps, compressors, fans, mixers, packaging equipment, and industrial drive systems where dependable torque transmission and easy servicing are required.

Technical Specifications:

• Manufacturer: Tsubaki Emerson Co.
• Model / Part Number: CR5108
• Product Type: Roller Chain Coupling Kit
• Series: CR Series
• Coupling Components: 2 × CR5018-J Coupling Sprockets, 1 × CR5018 Duplex Roller Chain
• Bore Size: 32 mm Finished Bore
• Coupling Type: Wrap-Type Roller Chain Coupling
• Chain Size: CR5018 Duplex Roller Chain
• Number of Teeth: 18 (per sprocket)
• Material: Surface-hardened steel sprockets with duplex roller chain
• Maximum Shaft Bore Capacity: 45 mm (CR5018 Series)
• Allowable Transmission Torque: 931 N·m (686 lb-ft)
• Mounting: Keyed shaft mount
• Function: Flexible shaft coupling for torque transmission and shaft misalignment compensation
• Application: Conveyors, pumps, compressors, mixers, packaging machinery, and material handling equipment

Common Replacements:

• Tsubaki CR5018-J Roller Chain Coupling
• Tsubaki CR6018-J Roller Chain Coupling
• Tsubaki CR6022-J Roller Chain Coupling
