TSUBAKI RS100-4CB Quadruple-Strand ANSI Roller Chain

Description:

The Tsubaki RS100-4CB Roller Chain is a quadruple-strand ANSI roller chain designed for heavy-duty power transmission and conveyor applications requiring high strength and long service life. Commonly installed in industrial conveyors, mining equipment, material handling systems, agricultural machinery, packaging equipment, and manufacturing production lines utilizing ANSI No. 100 chain. Maintenance technicians, machine builders, and system integrators use this roller chain for equipment repair, preventive maintenance, drive system upgrades, and replacement of worn OEM chain assemblies. The 100-4CB features a cottered pin construction and is supplied in a 10-foot length.

Applications:

The Tsubaki RS100-4CB Roller Chain is commonly used in heavy-duty conveyor systems, bulk material handling equipment, steel mills, forestry machinery, agricultural equipment, industrial drives, and process manufacturing systems where high load capacity and reliable power transmission are required. Its four-strand design provides increased tensile strength and load distribution for demanding continuous-duty applications.

Technical Specifications:

• Brand: Tsubaki
• Model: RS100-4CB
• Part Number: 100-4CB
• Product Type: Quadruple-Strand Roller Chain
• ANSI Chain Size: No. 100
• Chain Construction: Cottered Pin (CB)
• Number of Strands: 4
• Chain Pitch: 1.250 in.
• Roller Diameter: 0.750 in.
• Width Between Inner Plates: 0.750 in.
• Transverse Pitch: 1.408 in.
• Pin Diameter: 0.375 in.
• Minimum Ultimate Strength: 78,120 lb
• Average Tensile Strength: 105,840 lb
• Maximum Allowable Load: 16,730 lb
• Number of Links per 10 ft: 96
• Overall Length: 10 ft
• Material: Heat-Treated Carbon Steel
• Application: Heavy-Duty Industrial Power Transmission and Conveyor Systems

Common Replacements:

• Tsubaki RS100-4RB Quadruple-Strand Roller Chain
• Renold ANSI 100-4 Cottered Roller Chain
• Diamond Chain ANSI 100-4 Cottered Roller Chain
