Veris Industries Z201733-0E Current Sensing Switch

Description:

The Veris Industries Hawkeye 800 Z201733-0E Current Sensing Switch is a solid-core current monitoring device designed to detect AC current flow and provide a switched output for building automation and industrial control systems. With a fixed trip point and a 1 A output rating at 30 VAC/DC, this sensor offers reliable equipment status monitoring without requiring an external power supply. It is commonly used by facility managers, HVAC technicians, and automation professionals to monitor motors, fans, pumps, and other electrical loads.

Applications:

The Veris Hawkeye 800 Current Sensing Switch is commonly used in HVAC systems, building automation systems (BAS), exhaust fans, unit ventilators, fan coil units, recirculation pumps, lighting circuits, and industrial equipment where dependable on/off current status monitoring is required. It is particularly well suited for direct-drive loads and fixed-current applications.

Technical Specifications:

• Manufacturer: Veris Industries
• Model: Hawkeye 800
• Part Number: Z201733-0E
• Product Type: Current Sensing Switch
• Sensor Type: Solid-Core Current Switch
• Current Measurement Range: 0.25–200 A AC
• Fixed Trip Point: 0.25 A maximum
• Output Type: Normally Open (N.O.) Solid-State Switch
• Output Rating: 1 A @ 30 VAC/DC
• Monitored Frequency: 50/60 Hz
• Maximum Conductor Size: 0.71 in. (18 mm) Diameter
• Operating Temperature: -40°F to 122°F (-40°C to 50°C)
• Power Requirement: Self-powered (induced from monitored conductor)
• Certifications: UL, CE
• Designed for Building Automation and Industrial Monitoring Applications

Common Replacements:

• Veris Hawkeye H800
• Veris Hawkeye H800NC
• Veris Hawkeye H600 Current Sensing Switch
