Yaskawa JANCD-YFC22-E Machine Safety Terminal Block

Description:

The Yaskawa JANCD-YFC22-E is a machine safety terminal block and breakout circuit board used in Yaskawa Motoman DX200 robotic controllers to interface external safety signals with the controller’s safety I/O system. Commonly applied in robotic welding, material handling, and automated production systems requiring emergency stop circuits, safety interlocks, and external enable/hold controls. Purchased by maintenance teams, OEMs, and integrators for replacement, repair, or retrofit of safety-critical control hardware to maintain compliance and system uptime.

Applications:

The Yaskawa JANCD-YFC22-E board is used in industrial robotics environments where safety signal integration is critical. It is commonly deployed in DX200 robot controllers where it connects external devices such as emergency stop buttons, safety relays, enable switches, and safety outputs to the controller. This ensures proper safety circuit functionality including servo enable, hold, and emergency stop operations across robotic systems.

Technical Specifications:

• Manufacturer: Yaskawa Electric
• Model / Part Number: JANCD-YFC22-E
• Product Type: Machine Safety Terminal Block / Breakout PCB
• Function: Interfaces external safety signals with controller safety I/O
• System Platform: Yaskawa Motoman DX200 robotic controllers
• Signal Type: Safety I/O (E-stop, enable, hold, servo ON, safety outputs)
• Role: External safety device integration and signal routing
• Installation: Internal mounting within robot controller cabinet
• Construction: Industrial PCB with terminal block connections
• Category: PLC / control add-on board
• Weight: ~0.04 lbs (board only)
• Status: Discontinued / legacy component
• Availability: Typically surplus, refurbished, or repairable

Common Replacements:

• Yaskawa JANCD-YSF22-E
• Yaskawa JANCD-YSF24-E
• Yaskawa JANCD-YIO21-E
