Yaskawa SGDG-04GT Servo Driver SGDG04GT

Description:

The Yaskawa SGDG-04GT is a servo amplifier designed for precise motion control in high-performance automation systems. Part of the Servopack series, it supports analog voltage and pulse train command inputs and is compatible with Yaskawa’s Sigma series servo motors. The SGDG-04GT is engineered for dynamic response and accurate position, speed, and torque control. Its compact design, built-in diagnostics, and protective functions make it ideal for applications such as robotics, CNC machines, and automated assembly lines.

TECHNICAL SPECIFICATIONS:

Model: SGDG-04GT
Series: Servopack (Sigma Series)
Rated Output: 400W
Input Voltage: 1-phase or 3-phase 200–230V AC, 50/60 Hz
Control Modes: Position, Speed, and Torque Control
Command Interface: Analog voltage input, pulse train input
Compatible Motors: Yaskawa Sigma series (e.g., SGM or SGMAH motors)
Encoder Feedback: Incremental encoder support
Protection Features: Overcurrent, overvoltage, overheating, encoder error, regenerative error
Mounting: Panel mount
Cooling Method: Natural convection
Ambient Temperature: 0°C to 55°C (32°F to 131°F)
Communication Port: RS-232/RS-422 for setup and diagnostics
Dimensions: Approx. 130 mm x 180 mm x 60 mm (H x W x D)
Weight: Approx. 1.5 kg (3.3 lbs)
