Yaskawa SGDS-02A12A Servo Drive SGDS02A12A

Description:

SGDS02A12A DISCONTINUED BY MANUFACTURER SERVO AMPLIFIER INPUT: 2.4AMP 1PHASE 200-230VAC 50/60HZ OUTPUT: 2.1AMP 3PHASE 0-230VAC 0-300HZ 200W The Yaskawa SGDS-02A12A is a reliable and efficient AC servo drive designed for high-performance motion control applications. Engineered to deliver precise control and exceptional performance, this drive supports advanced vector control technology, ensuring accurate speed, torque, and positioning. With a focus on durability and ease of integration, the SGDS-02A12A is well-suited for various industrial automation tasks, offering seamless compatibility with Yaskawa's servo motors. It features a compact design, user-friendly interface, and robust construction, making it ideal for applications where reliability and precision are critical.

Technical Specifications:

• Model: SGDS-02A12A
• Type: AC Servo Drive
• Rated Output Current: 1.2 A
• Rated Voltage: 200-230 V AC, Single-phase
• Power Supply Frequency: 50/60 Hz
• Control Method: Vector control with encoder feedback
• Communication Protocols: Optional communication boards for various fieldbus protocols (e.g., RS-232, RS-485)
• Safety Functions: Basic safety functions including overcurrent and overheating protection
• Cooling Method: Forced air cooling
• Protection Rating: IP20
• Mounting: Panel mount
• Operating Temperature Range: 0 to 40°C (32 to 104°F)
• Weight: Approximately 1.5 kg (3.3 lbs)
• Dimensions: 130 mm x 110 mm x 160 mm (5.1 in x 4.3 in x 6.3 in)
