Yaskawa SGMPH-01A2A-YR12 Servo Motor SGMPH01A2AYR12

Description:

The Yaskawa SGMPH-01A2A-YR12 is a compact and efficient AC servo motor from the Sigma II series, designed for high-speed and high-precision motion control applications. With a rated power of 100W, it is ideal for small-scale automation systems requiring precise positioning and responsiveness. This model includes a straight shaft without a brake and features a high-resolution encoder for feedback control.

TECHNICAL SPECIFICATIONS:
Manufacturer: Yaskawa
Model Number: SGMPH-01A2A-YR12
Series: Sigma II
Type: AC Servo Motor
Rated Power: 100W
Rated Voltage: 200V AC
Rated Speed: 3000 RPM
Maximum Speed: 5000 RPM
Rated Torque: 0.318 Nm
Peak Torque: Approx. 0.95 Nm
Encoder Type: 17-bit Incremental Encoder
Shaft Type: Straight (no key)
Brake: No brake
Mounting: Flange mount
Protection Class: IP65 (excluding shaft and connectors)
Use Case: Semiconductor equipment, small robotics, medical devices, precision conveyors
